The LCSP-MF Wiegand reader offers double security by code and Mifare RFID card at your installation. The LCSP-MF reads Mifare Classic 1K & 4K, Ultralight and Desfire cards.
Designed to operate indoors or outdoors.
Features Specifications Support
Keypad with in-built Mifare RFID reader
The LCSP-MF offers double security to your installation: code, tag or code + tag.
The LCSP-MF reads Mifare Classic 1K & 4K, Ultralight and Desfire cards with a read range of 3 to 8 cm.
The keypad offers a user code length between 1 to 8 digits.
Network system
The LCSP-MF is a multi-protocol reader with backlit keys that needs to be connected to a Host. WIEGAND 26, 30, 34, 40 bits, Clock&Data or Codix protocol chosen directly from the keypad.
Rugged and smart
LCSP-MF reader is resistant to rain, UVA rays and dust.
| Mounting: | Surface |
|---|---|
| Housing: | ABS |
| Colours: | Grey |
| Technology: | Keypad + RFID |
| Protocol: | WIEGAND 26, 30, 34, 40 bits, Clock&Data or Codix |
| Reading type: | Mifare |
| Read range: | 3-8 cm |
| Visible signal: | Green and red LED: externally controlled
Orange LED: status |
| Audible signal: | Buzzer |
| Voltage: | 12 V DC |
| Consumption: | 120 mA |
| Mechanical Characteristics | |
| Indoor/outdoor use: | Both |
| Dimensions (L x H x W): | 84 x 120 x 38 mm (with 43B housing) |
| Weight: | 150 g |
| Operating temperature: | -20ºC to +50ºC |
| Operating humidity: | 5% to 95% RH(non-condensing) |
| * All product specifications are subject to change without notice. | |
