Exit Devices
Sensitive or Infrared Exit devices
Elegant request-to-exit solutions that complement any access control system with a simple touch or a wave of the hand.
Features Specifications Support Related products
XPR / Solutions / Accessories / Exit devices / Exit Devices
Specification Tables
XP-PB & XPM-PB – Ultimate REX device for Xpro range
Resilient capacitive surface-mount buttons designed in universal single gang and mullion formats. The perfect aesthetic and technical match for a seamless Xpro installation.
MTT – Surface-Mount Sensitive Exit Button
The MTT offers aesthetic compact housing appearance and different colours choices suitable for any environment. It is an entirely electronic, non-mechanical and ergonomically designed access control device. It can either function as an independent manually controlled push button or be connected to a controller to facilitate access from a secure area.
MTT-IR – Surface-Mount Infrared Contactless Exit Button
The MTT-IR request to exit with infra-red technology provides contactless features allowing relay activation by hand waving.
TBS Compact Sensitive Exit Button
Stainless steel touch. Ideally suited for a wide range of applications e.g., Exit button, light switch, elevator button or industrial panels.
DINMTT – Slim Flush-Mount Sensitive Exit Button
The DINMTT is one of the DIN Range products. This range offers unique features like the same aesthetic ABS mask appearance and different colours choices suitable for any environment. It is an entirely electronic, non-mechanical and smart-designed access control device. It can either function as an independent manually controlled push button or be connected to a controller to facilitate access from a secure area.
Specification Tables
| Relay time: | Pulse and latch mode |
|---|---|
| Visible signal: | Red LED: Stand by Green LED: relay operation |
| Audible signal: | Buzzer |
| Relay output: | 2 A at 24 DC/ 120 V AC |
| Voltage: | 12-24 V DC; 15-24 V AC |
| Operating temperature: | -20ºC to 50ºC |
| Operating humidity: | 0-95% non-condensing |
| XP-PB | XPM-PB | MTT | MTT-IR | TBS | DINMTT | |
|---|---|---|---|---|---|---|
| Mounting: | Surface | Surface | Surface | Surface | Surface | Flush |
| Housing: | Polycarbonate Copolymer (UL94) | Polycarbonate Copolymer (UL94) | Moulded aluminium/ABS | ABS | Die-cast aluminium alloy | ABS (sold separately) |
| Colours: | Black | Black | Aluminium: silver ABS: black | Silver and Black | Matt Chrome | Silver, charcoal, white |
| Resin potted electronic: | Yes | Yes | Yes | Yes | Yes | No |
| Technology: | Capacitive | Capacitive | Capacitive | Infrared | Capacitive | Capacitive |
| Touch plate: | – | – | Stainless steel | Acrylic | Mild Steel | Stainless steel |
| Consumption: | Max. 65 mA | Max. 65 mA | Max. 65 mA | < 50 mA | Max. 65 mA | Max. 65 mA |
| IP rating: | IP65 | IP65 | IP65 | IP66 | IP66 | IP40 |
| Dimensions (L x H x W): | 51x92x27 mm | 38x92x25 mm | 51x92x27 mm | 51x92x27 mm | 86x116x22 mm | 80x80x9 mm |
| Weight: | ~150 g | ~120 g | ~150 g | ~150 g | ~280 g | ~150 g |
| Same style as the following products: | Xpro range | Xpro range | Xsmart range, MTPX, BIOPROX, MTPADP-EH-SA, MTPADP-RS, MTPX-RS | Xsmart range, MTPX, BIOPROX, MTPADP-EH-SA, MTPADP-RS, MTPX-RS | VPROX2-M, VKP99, VKP | DIN range |
| XP-PB | Surface – Capacitive push button – Polycarbonate Copolymer (UL94) – Black |
|---|---|
| XPM-PB | Surface – Mullion – Capacitive push button – Polycarbonate Copolymer (UL94) – Black |
| MTTS: | Surface – Capacitive push button – Metal – Silver |
| MTTBK: | Surface – Capacitive push button – ABS – Black |
| MTTS-IR: | Surface – Infrared push button – Metal – Silver |
| MTTBK-IR: | Surface – Infrared push button – ABS – Black |
| TBS: | Surface – Capacitive push button – Metal – Matt Chrome |
| DINMTT-E: | Flush Mount – Capacitive push button – Electronic only |
All product specifications are subject to change without notice.
