LCS
Multi-protocol Keypad Readers with or without RFID
The LCS2 and LCSP-MF readers are designed to meet your access control needs with code-only or dual authentication using an RFID card, offering flexible and secure solutions for both indoor and outdoor installations
Features Specifications Support Related products
XPR / Solutions / ONLine Access / Keypads / LCS
Features
Network system
LCS is a multi-protocol reader with backlit keys that needs to be connected to a Host. Wiegand 26, 30, 34 or 40 bits, Data/Clock or CODIX protocol chosen directly from the keypad.
Blue backlit keypad
The LCS-range comes with an elegant blue backlight.
The keys are available in metal or plastic.
The 3 LEDs on the top of the keypad are free and used to indicate the status of the keypad:
Green: access granted/alarm OFF
Red: access denied/alarm ON
Orange: key press and menu.
Rugged and smart
LCS keypads are resistant to rain, UVA rays and dust.
Keypad with in-built RFID Reader
The LCSP offers double security to your installation: code, tag or code + tag.
The keypad offers a user code length between 1 to 8 digits.
The LCSP-MF reads Mifare Classic 1K & 4K, Ultralight and Desfire cards with a read range of 3 to 8 cm.
Specifications
| Mounting: | Surface/Flush |
|---|---|
| Housing: | ABS/moulded aluminium, Steel A304 |
| Protocol: | Compatible with WIEGAND 26, 30, 34, 40 bits, Clock & Data or Codix |
| Keys: | Backlit metal/plastic keys |
| Visible signal: | 2 free tension LEDs (Red & Green) |
| Audible signal: | 1 buzzer |
| Voltage: | 12 V DC |
| Consumption: | Standby: 5 mA Max: 30 mA |
| IP rating: | IP65 |
|---|---|
| Dimensions (L x H x W): | 43B housing: 84 x 120 x 40 mm 72C/73C housing: 90 x120 x 40 mm 102A/103A housing: 105 x 140 mm 62A: 113.24 x 91 x 49.03 mm |
| Weight: | ~300 g |
| Operating temperature: | -20°C to +50°C |
| Operating humidity: | 0 to 95% (non-condensing) |
| LCS2 | LCSP-MF | |
|---|---|---|
| Technology: | Keypad | Keypad + RFID |
| Consumption: | Standby: 5 mA Max: 30 mA | 120 mA |
| Reading type | No | Mifare |
| Reading range | No | 3-8 cm |
| LCS2-43B | Matt white ABS – surface mount keypad – backlit plastic keys – Multi-Wiegand |
|---|---|
| LCS2M-43B | Matt white ABS – surface mount keypad – backlit metallic keys – Multi-Wiegand |
| LCS2-72C | Grey moulded aluminium – surface mount keypad – backlit plastic keys – Multi-Wiegand |
| LCS2M-72C | Grey moulded aluminium – surface mount keypad – backlit metallic keys – Multi-Wiegand |
| LCS2-102A | Brushed stainless steel A304- flush mount keypad – backlit plastic keys – Multi-Wiegand |
| LCS2M-102A | Brushed stainless steel A304 – flush mount keypad – backlit metallic keys – Multi-Wiegand |
| LCS2-62A | Brushed stainless steel A304- surface mount keypad – backlit plastic keys – Multi-Wiegand |
| LCS2M-62A | Brushed stainless steel A304- surface mount keypad – backlit metal keys – Multi-Wiegand |
| LCSP-MF-43B | Matt white ABS – surface mount keypad – backlit plastic keys – Multi-Wiegand – MIFARE |
| LCSPM-MF-43B | Matt white ABS – surface mount keypad – backlit metallic keys – Multi-Wiegand – MIFARE |
All product specifications are subject to change without notice.
