MTPX-RS
EH or Mifare Reader
Elegant and compact 125 kHz or 13.56 MHz
RFID reader. The housing, in ABS, comes with a big rectangular LED. Designed to be installed either outside or inside, it has an RS-485 bus. Its tricolor LED, tamper and buzzer are managed directly by the WS4 controllers. It can read EM or HID 125 kHz cards depending on the programming selected or Mifare Classic, Desfire and Ultralight cards.Features Specifications Support Related products
XPR / Solutions / Web Access / RFID Readers / MTPX-RS
Features
RFID Reader
The MTPX-RS-EH reads EM4002/4100 and HID 125 kHz compatible cards with a read range of up to 5 cm distance.
The MTPX-RS-MF reads Mifare Classic, Ultralight and Desfire cards with a read range of 6 cm distance.
RS-485 output
It works with an RS-485 output, establishing a double communication between the reader and the WS4 controllers, reducing the number of wires needed in the installation.
Mullion RFID reader
The MTPX-RS with its slim housing is suitable for doorframe mounting.
It comes also with a large LED around the reader for an easy and stylish reading of the status of the door.
Specifications
| Mounting: | Surface |
|---|---|
| Housing: | ABS |
| Colours: | Black / Silver |
| Technology: | RFID |
| Output: | RS-485 |
| Visible signal: | – Green LED: Access granted – managed by the host – Red LED: Access denied – managed by the host – Orange LED: idle mode (ON/OFF) |
| Audible signal: | 1 internal buzzer (ON/OFF) – managed by the host |
| Tamper protection: | Yes – managed by the host |
| Voltage: | 9-14 V DC |
| IP rating: | IP65 |
|---|---|
| Dimensions (L x H x W): | 51 x 92 x 27 mm |
| Weight: | ~0.15 kg |
| Operating temperature: | -20°C to +50°C |
| Operating humidity: | 5% to 95% RH without condensation |
| MTPX-RS-EH | MTPX-RS-MF | |
|---|---|---|
| Reading type: | EM 4002/4100 and HID | Mifare Classic, Desfire and Ultralight |
| Read range: | Up to 5 cm | Up to 6 cm |
| Operating frequency: | 125 kHz | 13.56 MHz |
| Consumption: | Max. 50 mA | Max. 130 mA |
| MTPXBK-RS-EH V2: | EH reader – ABS – Black |
|---|---|
| MTPXS-RS-EH V2: | EH reader – Silver |
| MTPXBK-RS-MF V2: | Mifare reader – ABS – Black |
| MTPXS-RS-MF V2: | Mifare reader – Silver |
All product specifications are subject to change without notice.
