TX Transmitters
868 MHz Transmitters
The TX family has a high signal range of up to 100 meters in the open space. It provides maximum comfort and reliability thanks to its APS and security code-changing systems.
Refs: TX2W (2 channels)
TX4W (4 channels)
Features Specifications Support Related products
XPR / Solutions / ONLine Access / Radio / TX Transmitters
Features
Easy and quick installation
No need of long wire connections to install a radio system with the transmitters. They can be programmed very easily with the EWS and Web Access software.
APS- Approaching System
Thanks to the Approaching System (APS), the radio receiver gets the signal fast from the TX radio transmitters:
1. The user activates the radio transmitter before reaching the radio coverage area.
2. Within 15 seconds, the user enters the coverage area. The door is still closed, but the user does not need to press again any button.
3. The radio receiver gets the signal and opens the door.
Specifications
| TX2W | TX4W | |
|---|---|---|
| Channels (buttons): | 2 | 4 |
| Technology: | Radio | Radio |
| Frequency: | 868 MHz | 868 MHz |
| Nominal range: | 100 m | 100 m |
| Battery: | CR2032, 3V | CR2032, 3V |
| Battery life: | 2 years | 2 years |
| Consumption: | 12 mA | 12 mA |
| Rolling code: | Yes | Yes |
| LED Indicator: | Transmit and low battery | Transmit and low battery |
| Operating temperature: | -20°C to +55°C | -20°C to +55°C |
| Dimensions (L x H x W): | 55 x 30 x 10 mm | 62 x 33 x 11 mm |
All product specifications are subject to change without notice.
Support
- DownloadTX Transmitters Data Sheet - EN
