VKP
Elegant Vandal-Resistant Wiegand Keypad
Vandal-proof VKP is designed for high-security applications in a hostile environment. This model works with a Host and the protocols (CODIX, DATA/CLOCK or WIEGAND) are set directly from the keypad.
Features Specifications Support Related products
XPR / Solutions / ONLine Access / Keypads / VKP
Features
Network system
Multi-protocol peripheral unit (WIEGAND 26-bit / 30-bit, DATA/CLOCK, CODIX)
Rugged and smart
VKP keypad is resistant to rain, UVA rays and dust.
The keypad comes with resin-potted electronic.
Specifications
| Mounting: | Surface |
|---|---|
| Housing: | Moulded aluminium |
| Colours: | Matt Chrome |
| Resin potted electronic: | Yes |
| Technology: | Keypad |
| Protocol: | Compatible to any Host with 26 or 30-bit Wiegand, Clock & Data or Codix protocol |
| Keys: | Metallic keys |
| Visible signal: | 1 Red LED (voltage free) 1 Green LED (voltage free) 1 Yellow LED (status and error information) |
| Audible signal: | 1 buzzer |
| Wiring: | 8-core cable |
| Voltage: | 9/12 V DC |
| Consumption: | Standby 10 mA Max. 30 mA |
| IP rating: | IP65 |
|---|---|
| Dimensions (L x H x W): | 86 x 116 x 22 mm |
| Weight: | ~0.42 kg |
| Operating temperature: | -20°C to +50°C |
| Operating humidity: | 0 to 95% (non-condensing) |
All product specifications are subject to change without notice.
